Description
Get the most out of your pool heating investment!
Features:
- High performance titanium heat exchanger (Patented ThermoLink® in the T90, T115 and T135 models)
- Microprocessor controlled defrost cycle allows operation down to mid to low 40s °F
- Built-in drain pan for condensate management
- Impact resistant, rust and fade proof cabinet
- Quieter than conventional heat pumps
- NEW Smart Microprocessor Control with LCD Display
- Flip-out, lockable control panel is protected against sun and weather and can be easily programmed to prevent others from tampering with settings
- Digital control panel with 24 character full-text display provides easy-to-read menu options and unit status
- Ability to connect to most external controllers
- Hybrid functionality can initiate a gas heater when an extra boost of heat is needed
Specifications:
- Efficiency
- KW Output: 10.6
- BTU Output: 36,000
- Coefficient of Performance (water temp/ambient air/relative humidity): 6.2
- KW Input: 1.7
- Electrical
- Voltage/Hz/Phase: 220-240/50/1
- Minimum Circuit Ampacity
- Maximum Fuse Size: 20
- Minimum Circuit Ampacity: 12.2
- Heat Exchanger: Tube in Tube
- Water flow
- Min./Max. water Flow (m³/h): 4.5/10.2
- Min./Max. water Flow (gpm): 20/45gpm
- Physical
- Weight (kg): 82
- Weight (lb): 180
- Length x Width x Height (cm): 92 x 64 x 72
- Length x Width x Height (in): 36″ x 25″ x 28″
- Shipping
- Weight (kg): 100
- Weight (lbs): 220
- Length x Width x Height (cm): 97 x 66 x 84
- Length x Width x Height (in): 38″ x 26″ x 33″
