Description
Features:
Get the most out of your pool heating investment!
- High performance titanium heat exchanger (Patented ThermoLink® in the T90, T115 and T135 models)
- Microprocessor controlled defrost cycle allows operation down to mid to low 40s °
- Built-in drain pan for condensate management
- Impact resistant, rust and fade proof cabinet
- Quieter than conventional heat pumps
- NEW Smart Microprocessor Control with LCD Display
- Flip-out, lockable control panel is protected against sun and weather and can be easily programmed to prevent others from tampering with settings
- Digital control panel with 24 character full-text display provides easy-to-read menu options and unit status
- Ability to connect to most external controllers
- Hybrid functionality can initiate a gas heater when an extra boost of heat is needed
Specifications:
- BTUs (water temp/ambient air/relative humidity):
- 80/80/80: 74,000
- 80/80/63: 70,000
- 80/50/63: 49,000
- Coefficient of Performance (water temp/ambient air/relative humidity):
- 80/80/80: 5.6
- 80/80/63: 5.4
- 80/50/63: 4.0
- Refrigerant: R410A
- Heat Exchanger: Tube in Tube
- Electrical:
- KW Input: 3.9
- Voltage/Hz/Phase: 208-230/60/1
- Minimum Circuit Ampacity: 31.4
- Maximum Fuse Size: 50
- *Over Temperature Alarm Kit available: part number STK0221 for single phase, STK0222 for three phase. Strongly recommended for all spa applications.
- Water Flow:
- Minimum/Maximum (gpm): 20/45
- *A Heater Bypass Kit is required when flow rates exceed the maximum: part number STK0135.
- Physical:
- Weight (lbs): 200
- Size (LxWxH): 34″ x 34″ x 28″
- Shipping:
- Weight (lbs): 240
- Size (LxWxH): 38″ x 36″ x 33″
