Description
Waterway E-Series Wet End 310-1141
Product Overview
As a retailer of hot tub spare parts, I’m excited to present the Waterway E-Series Wet End (310-1141), engineered for superior performance in high-demand spa applications. This 2.0HP model represents Waterway’s dedication to engineering excellence since 1973, offering enhanced flow rates and reliable operation.
Key Features
- Robust 48Y frame design
- 1½” MBT intake and center discharge ports
- Enhanced 2.0HP capacity for powerful performance
- Full 360-degree rotatable housing
- Optimized impeller design for maximum efficiency
- Streamlined water flow path
- Heavy-duty thermoplastic construction
Applications
Perfectly suited for:
- High-performance hot tubs and spas
- Systems requiring stronger water flow
- Multiple jet configurations
- Demanding hydrotherapy applications
- Commercial and residential installations
Installation Flexibility
The innovative rotating design allows for optimal positioning in any installation scenario. This feature proves invaluable when working with existing plumbing configurations or in tight installation spaces, reducing the need for additional fittings or modifications.
Technical Specifications
| Specification | Detail |
|---|---|
| Model Number | 310-1141 |
| Series | E-Series |
| Frame Size | 48Y |
| Horsepower Rating | 2.0 HP |
| Intake Size | 1½” MBT |
| Discharge Size | 1½” MBT |
| Discharge Location | Center |
| Material | High-impact thermoplastic |
| Rotation | 360 degrees |
| Motor Compatibility | ¾ to 2 HP |
Performance Benefits
This 2.0HP wet end delivers:
- Higher flow rates for enhanced circulation
- Improved jet performance
- Efficient water movement
- Reduced energy consumption through optimized design
- Quiet operation
Engineering Excellence
Built with precision engineering, this wet end incorporates:
- Balanced hydraulic design
- Optimized volute geometry
- High-efficiency impeller
- Precision-molded components
- Chemical-resistant materials
Installation Considerations
- Compatible with standard 48Y frame motors
- Direct replacement for existing E-Series installations
- Versatile mounting options
- Simple alignment process
- Universal port configurations
Maintenance Recommendations
- Periodic inspection of seals
- Regular cleaning of intake screens
- Proper winterization when required
- Maintaining correct water chemistry
- Regular inspection for optimal performance
Alternate Part Numbers
- 1-05-0337
- 310-1141B
- 310-8240 (Waterway)
- 34-270-1120
